Turn-Mill Machining Center
580mm X Axis Travel Plus, an extra-long work table provides a large tool mounting area. This allows for a large number and variety of table mounted tooling options. This capacity makes the SL580M a powerful, “single set-up” turning center for turning, milling, tapping and drilling operations in a single part production cycle. Smart operators can combine operations into a single machining center-saving on capital input an operating costs. SL580M owners report they have gained a competitive advantage with the addition of these machines to their production system.

Machine Characteristics
• High quality castings provide optimal damping – reducing vibration and increasing rigidity. Best assurance of quality surface finishes.
• Advances 90˚ vertical machine structure optimizes chip and coolant flow – PLUS, provides easy operator access for work and tool set-up.
• Single Set-up allows for turning, milling, drilling and tapping operations.
• Capable of C axis and 4 axis simultaneous machining.
• Modular design with many available configurations – such as tall stock and tooling combinations.


Chuck/ Collet: Hydraulic collet, *6”chuck, *8″
Max. swing over way cover: ∅400mm
Max. cutting length: 250mm
Max. swing. Over slide: ∅250mm


Spindle type: A2-5
Spindle Bore: Ø48mm
Drawbar Capacity: Ø40mm
Max. Spindle speed:4500rpm
Spindle Power: 5.5/ 7.5 kW

Spindle type: *A2-5
Spindle Bore: *Ø55mm
Drawbar Capacity: *Ø46mm
Max. Spindle speed: *4500rpm
Spindle Power: 5.5/ 7.5 kW

Spindle type: *A2-5
Spindle Bore: *Ø62mm
Drawbar Capacity: *Ø52mm
Max. Spindle speed: *4000rpm
5.5/7.5 kW


X Axis Travel: 220mm
Z Axis Travel: 320mm
Y Axis Travel: 300mm
X/ Y/ Z Rapid Traverse: 12/12/12 m/min


Gang type tool mixed with livetoolings


Tailstock taper: MT4
Tailstock quill travel: 100mm


Bed incline degree: 90˚
Guideway type: Linear motion


Power Capacity: 14 kVA
Overall Dimension(L×W×H) 2350 ×1800 ×2300mm
Weight(about): 3500Kgs
